Beschreibung
RAHMENSET
- Rahmen: Spark Alloy SL 6011, Integrated Suspension Technology, Flex Pivot / Adjustable head angle, Syncros Cable Integration System, BB92 / UDH Interface / 12x148mm with 55mm Chainline
- Gabel: RockShox Judy Silver TK Solo Air, 15x110mm QR axle / 42mm offset / Tapered Steerer, 2-Modes / Reb. Adj. / Lockout / 130mm travel
- Dämpfer / Federbein: X-Fusion NUDE 5 RLX Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, Reb. Adj., Travel 120-80-Lockout / T165X45mm
- Steuersatz: Syncros – Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB
AUSSTATTUNG
- Lenker: Syncros Fraser 2.0 DC Alloy 6061 D.B., Mini Rise / back sweep 8° / 740mm
- Lenkerfernbedienung: SCOTT TwinLoc 2 Technology, Suspension & Dropper Remote, 3 Suspension modes
- Lenkerbreite: 740
- Vorbau: Syncros DC 3.0, Syncros Cable Integration System, 0° rise / 6061 Alloy / 31.8mm / 1 1/8″
- Vorbaulänge: 50,0
- Griffe: Syncros Performance XC lock-on grips
- Sattel: Syncros Savona 2.5 V-Concept
- Sattelstütze: Syncros Duncan Dropper Post 2.5, 31.6mm / S size 100mm / M size 125mm / L size 150mm
ANTRIEB
- Schaltwerk: Shimano XT RD-M8100 SGS, Shadow Plus / 12 Speed
- Schalthebel: Shimano Deore SL-M6100-R / Rapidfire Plus
- Anzahl Gänge: 12
- Kurbelsatz: Shimano FC-MT512-1, 55mm CL / 30T
- Innenlager: Shimano BB-MT500 / shell 41x92mm
- Kette: KMC X12
- Zahnkranz (hinten): Shimano Deore CS-M6100-12 / 10-51 T
